Dawb 1 High Alumina Ceramic Raschig Nplhaib Raws li Pawg Txhawb Kev Tshaj Tawm hauv Kev Lag Luam Tshuaj
Raws li ib qho ntawm cov kws tshaj lij manufacturers ntawm nto moo hom 'Ceramic Raschig Nplhaib, peb sov siab txais tos koj mus yuav cov dawb 1 siab alumina ceramic raschig nplhaib raws li huab hwm coj xov xwm hauv kev lag luam tshuaj hauv Tshuag los ntawm peb. Tus nqi qis thiab kev pabcuam zoo tom qab muag yuav raug muab.
Dawb 1 "siab alumina ceramic raschig nplhaib raws li kev txhawb nqa loj hauv kev lag luam tshuaj
Product Description.
Ceramic raschig nplhaib yog ib txwm ntim khoom uas lawv tau siv rau rov ua cov khoom siv uas twb muaj lawm thiab lwm yam kev siv. Raschig nplhaib muaj cov khoom zoo heev ntawm cov cua sov thiab cov kua qaub, uas tuaj yeem tiv thaiv corrosion ntawm inorganic acids, organic acids thiab organic hnyav thiab kuj tuaj yeem siv rau ntau lub sijhawm kub lossis qis.
1. Specification.
|
Qauv: |
Raschig Nplhaib |
||||||
|
Cov duab: |
Nplhaib |
||||||
|
Xim: |
Lub Teeb Grey |
||||||
|
Tshuaj muaj pes tsawg leeg |
|||||||
|
SiO 2 |
Al2O3 |
Fe2O 3 |
CaO |
K2O plus Na2O |
|
||
|
>70 feem pua |
17-23 feem pua |
<1% |
<1-2% |
<2-4% |
|||
|
Technical data |
|||||||
|
Txoj kab uas hla (mm) |
D * H * T (mm) |
Qhov chaw (m 2 / m3) |
Dawb ntim (%) |
Number rau m3 |
Qhov ceev (Kg / m3) |
Cov khoom ntim qhuav (m-1) |
|
|
15 |
15*15*2 |
330 |
70 |
250000 |
690 |
960 |
|
|
16 |
16*16*2 |
305 |
73 |
192500 |
730 |
784 |
|
|
25 |
25*25*2.5 |
190 |
78 |
49000 |
505 |
400 |
|
|
40 |
40*40*5 |
126 |
75 |
12700 |
577 |
305 |
|
|
50 |
50*50*5 |
93 |
81 |
6000 |
457 |
177 |
|
|
80 |
80*80*9.5 |
90 |
68 |
1910 |
714 |
234 |
|
|
100 |
100*100*10 |
70 |
70 |
1000 |
700 |
172 |
|
|
150 |
150*150*15 |
50 |
68 |
295 |
790 |
142 |
|
|
Lub cev muaj zog |
|||||||
|
Index |
Tus nqi |
||||||
|
Lub ntiajteb txawj nqus (g / cm3) |
2.25-2.35 |
||||||
|
Kev nqus dej (%) |
<0.5 |
||||||
|
Acid-resisting zog, feem pua Wt. Poob (ASTMc279) |
<4 |
||||||
|
Hluav taws kub kub (Degree C) |
1280-1320 |
||||||
|
Softening point (Degree C) |
>1400 |
||||||
|
Qhov ceev tshwj xeeb (kg / m3) |
2350 |
||||||
|
Pob: |
Jumbo hnab; Thawv thawv; Ntoo Case |
||||||
|
Warranty: |
a) Los ntawm National Standard HG-T 4369-2012 |
||||||
|
b) Muab kev sab laj rau lub neej ntawm cov teeb meem tshwm sim |
|||||||
2. Daim Ntawv Thov:
1). Nws yog qhov zoo tshaj plaws muab tub lim rau reburner, reacting rauv thiab muab tub lim rau roj thiab tshuaj industries.
2). Nws yog tsuas yog siv nyob rau hauv qhov kub thiab txias, kub siab, thiab muaj zog corrosion ua hauj lwm ib puag ncig ntawm tshuaj lom neeg kev lag luam.
3. Nta:
High-temperature kuj, muaj zog acid kuj .Simple qauv, yooj yim ua, txhim kho kev faib ntawm roj-kua thiab huab hwm coj hloov kev ua tau zoo.
4. Muaj Qhov Loj: 6mm, 10mm, 12mm, 15mm, 25mm, 50mm, 80mm, 100mm
Txheej txheem ntau lawm.
Khoom series
Cov ntaub ntawv tuam txhab.
Daim ntawv pov thawj.
FAQ.
1).Koj puas muab cov qauv? Puas yog dawb lossis ntxiv?
---Yog lawm, peb tuaj yeem muab cov qauv dawb tab sis tus nqi thauj khoom yuav tsum yog koj sab.
2). Puas yog CHEMXIN cov chaw tsim khoom lossis tuam txhab lag luam?
---Tus neeg tsim khoom.
3). Nws siv sijhawm ntev npaum li cas rau kev xa khoom?
{{0}Nyob rau hauv 7-10 hnub tom qab tau txais 30 feem pua ntawm tso nyiaj.
